    DIN HRC58 - HRC62 Side Feeder Venting Segmented Elements For Twin Screw Extruders

    Ask Lasest Price
    Brand Name : Nanxiang Machinery
    Model Number : As Requested
    Certification : ISO 9001
    Price : Negotiable
    Delivery Time : 30~60 days
    Payment Terms : L/C, T/T
    Supply Ability : 300M/Month
    • Product Details
    • Company Profile

    DIN HRC58 - HRC62 Side Feeder Venting Segmented Elements For Twin Screw Extruders


    DIN Standard HRC58-62 Hardness Side Feeder Venting Elements Side Feeder Segmented Elements for Twin Screw Extruders

    Product Description


    The Side Feeder Elements are treated with either polishing or sandblasting, depending on the customer's preference. The polishing treatment gives the elements a smooth and reflective surface, while the sandblasting treatment gives the elements a rougher texture. Both treatments provide added durability and resistance to wear and tear.


    DIN HRC58 - HRC62 Side Feeder Venting Segmented Elements For Twin Screw Extruders

    Technical Parameters


    Product NameSide Feeder ElementsDIN HRC58 - HRC62 Side Feeder Venting Segmented Elements For Twin Screw Extruders
    Screw DesignSingle Flighted
    Hardness58-60HRC
    Brand NameNanxiang Machinery
    Surface TreatmentPolishing/Sand Blasting
    SupplierFactory Direct
    Place of OriginSichuan , China
    StandardDIN, GB, Etc.
    ApplicationExtrusion Machine
    Suit ForPharmaceuticals Extrusion Chemical Extrusion Food Extrusion Powder Coating Extrusion

    Applications


    The Side Feeder Elements come in three types: Side Feeder Shearing Elements, Side Feeder Conveying Elements, and Side Feeder Pelletizing Elements.


    Support twin-screw extruder brand


    W&P: ZSK-MCBerstorff: ZE
    Leistritz: ZSE-MICROTheysohn: TSK
    Maris:TM-WAPV: MP65
    JSW: TEXSM: TEK-HS
    Feddem: FED-MTSFessia Macross: NRII
    TOSHIBA: TEMUSEON: TDS
    Labtech: LTESHIZHOU: MTE

    Reasons for Utilization


    1. Substantial reduction of wear costs in the melting section of the main screw and barrels
    2. Gentler and more delicate processing of fillers
    3. Considerable increase in throughput
    4. Significant increase in quality through adequate and sufficient fixing
    5. Substantial lowering of the cost


    Production Process


    Melting Zone Extruder Screw Elements 30° - 90° Angle Design Stable Performance 9

    NO.1


    Workblank


    Select high-quality raw materials


    NO.2


    Piecewise


    According to the drawing section length


    Melting Zone Extruder Screw Elements 30° - 90° Angle Design Stable Performance 10
    Melting Zone Extruder Screw Elements 30° - 90° Angle Design Stable Performance 11

    NO.3


    Hit bottom hole


    Rough machining the bottom hole,and then pull spline


    NO.4


    Machining thread


    Professional high-end processing equipment,rough machining threads


    Melting Zone Extruder Screw Elements 30° - 90° Angle Design Stable Performance 12
    Melting Zone Extruder Screw Elements 30° - 90° Angle Design Stable Performance 13

    NO.5


    Finish machining thread


    NO.6


    Threading grinding


    Further control of tolerance
    Length:-0.01mm-+0.01mm
    OD:-0.03mm-0mm
    Transition arc:-0.02mm-+0.02mm


    Melting Zone Extruder Screw Elements 30° - 90° Angle Design Stable Performance 14

    Our Service


    24-hour Hotline


    No matter when and where

    to call we can find our service to you.


    Pre-sales Consultation


    We have five sales people online,

    and whether you have any question

    can be solved through online

    communication,welcome your consultation.

    After-sales Services


    Receive products have any

    questions about the product,

    can look for us,we will help

    you deal with the the first time,to your satisfaction.


    All Nanxiang keep pay attention to every step of the details,We are looking forward to the forge ahead together with you!


    Product accuracy


    There are some differences between Nanxiang Machinery and Nanjing's production technology. Their finishing process is carried out before heat treatment, and the deformation after heat treatment is not controlled, so their accuracy is not easy to control. But our finishing process is carried out after heat treatment, which can eliminate the deformation of parts in heat treatment, so the precision is higher, and thus can achieve zero seam connection.


    Packing&Delivery


    Packing Details: According to your order quantity packaging, shipping wooden boxes, air carton.

    Delivery Details: 20-60days after order.


    DIN HRC58 - HRC62 Side Feeder Venting Segmented Elements For Twin Screw Extruders


    Packing


    According to your order quantities and products sizes to choose wooden boxes or cartons to pack:

    a. Rust-proof oil processing,

    b. Oiled paper packages,

    c. Bubble wrap package,

    d. Special foam packaging,

    e. Packing,

    f. Sealing.


    Customer Trust


    DIN HRC58 - HRC62 Side Feeder Venting Segmented Elements For Twin Screw ExtrudersDIN HRC58 - HRC62 Side Feeder Venting Segmented Elements For Twin Screw Extruders


    Certificate


    certificate nanxiang


    Why choose us?


    Nanxiang Machinery is a specialized manufacturer of precision-machined components for twin-screw extruders, including threaded elements, kneading blocks, mandrels, super-hard screw accessories, and wear-resistant alloy steel sleeves. Our products are widely applied in renowned international brands such as Coperion, Lerstritz, Berstorff, KOBE, and JSW, serving industries like plastics, food, feed, pellet manufacturing, pharmaceuticals, and new energy.


    DIN HRC58 - HRC62 Side Feeder Venting Segmented Elements For Twin Screw ExtrudersDIN HRC58 - HRC62 Side Feeder Venting Segmented Elements For Twin Screw Extruders


    FAQ


    Q: Are you a trading company or a manufacturer?

    A: We are a manufacturer.


    Q: Where is your factory located? How can I visit there?

    A: Our factory is located in Chengdu, Sichuan Province, China. You can fly directly to Chengdu Airport, and we will pick you up upon arrival. We warmly welcome all our clients, both domestic and international, to visit us.


    Q: How long will your product last?

    A: The lifespan of our products can vary greatly depending on the operation time, materials used, and working conditions. Therefore, it is difficult to provide an exact duration.


    Q: Are your quotations all FOB?

    A: Yes, all our quotations are FOB (Free on Board).


    Q: Can I get a one-year warranty for free?

    A: Our standard warranty is not free, but we have confidence in the quality of our products. If you require a warranty, it will be available for an additional cost.


    Q: How is your after-sale service?

    A: We are committed to providing timely support. If you encounter any issues with our products, you will receive our assistance promptly. We strive to ensure you receive the best service possible.
